Description
Key Features:
Ø High quality imaging with 8 MP resolution
Ø Up to 40m IR Distance
Ø 5x optical zoom allows for closer viewing of subjects in expansive areas
Ø Pan and tilt ability enables camera to monitor zones of interest
Ø RTSP and Onvf 17.06 compatible with many third-party NVR
Technical Parameters
Model | SNO-D60W-80P |
Camera | |
Image Sensor | 1/2.8″ CMOS |
Effective Pixels | 8 megapixels |
Electronic Shutter | AUTO, 1/25s ~ 1/100000s |
Min. Illumination | 0.01Lux@F1.2(AGC ON), 0Lux IR on |
Day/Night | Auto/Color/(B/W)/Timing |
WDR | Digital WDR , HDR |
White Balance | Auto/Manual |
AGC/BLC/HLC | Support |
DNR | 2D/3D DNR |
Other | Multi-lines OSD, Motion Detection, Privacy Mask, Mirror |
Encode | |
Video Standard | H.265+/H.265/H.264 |
Video Resolution | Main Stream: 20fps@3840×2160, 25fps@3072×2048,30fps@5MP/2560×1440/2304×1296/1920×1080/1280×720 Sub Stream: 30fps@D1/VGA(640×480)/640×360,480×360,CIF(352×288) Third Stream: 10fps@1080P/720P/CIF(352×288) |
Video Bitrates | 512Kbps – 8Mbps, VBR/CBR |
Audio Standard | G.711-u/G.711-a/AAC |
Built-in Mic | Yes, Audio Echo Cancellation |
Built-in Speaker | Yes, Two-way audio |
Memory Slot | Yes, maximum 512GB |
IR Led | |
IR Led | 8 pcs SMD Array IR Leds |
IR Distance | 30 -40M |
Lens | |
Focal length | 2.7-13.5mm Motorized AF |
Zoom | 5X Optical Zoom |
Smart Detection | |
Motion Detection | Support |
Target Detection | Human and Vehicle Detection |
PTZ | |
Pan/Tilt Range | Pan: 0° ~ 350°; Tilt: 0° ~ 87° |
Preset Point | 1 |
Control Speed | 50°/Sec |
Network Services | |
Protocol | HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP, etc. |
P2P | Yes |
Web | IE, Firefox, Chrome, Edge, Safari |
Media | CMS, Android, IOS |
General | |
Network Port | 1-RJ45, 100Mbps |
Power Supply | 12 VDC ± 10% |
POE | 802.3af/at 48V |
Power Consumption | < 8 W |
Operating Temp. | -20℃-(+60)℃, 10%-90%RH |
Support two-way audio
Built-in a integrated microphone and speaker, let you hear the sound around the camera,records what people say,
Motion Detection & Email Alert
Advanced H.265 Video Compression
Reduces file size up to 40%-50% with the same quality. save 40%-50% or more bandwidth H.265 (HEVC) doubles the coding efficiency compared with its predecessor H.264.That means that1. H.265 saves space; 2. store more videos; 3. provide super smooth to view video .
High Quality Night Vision Smart Infrared Cut Filter (ICR)
Camera has a very good night image quality. Infrared Cut Filter to ensure the highest quality images – day and night. During the day, the infrared cut filter drops in front of the lens to block the infrared lights from entering. This ensures that they do not affect the colors of the footage. When lighting levels become too low, this filter is automatically disengaged to allow the infrared light into the lens of the camera. This is when the full-color image turns to a monochrome black and white.
Waterproof All-weather Security Camera
POE Advantage, Why Choose POE ?
Don’t need extra power cables or adapters or switch.Plug And Play and easy setup.
Apply to multiple places
POE Connection, Don’t need Power Supply,No POE need USE 12v PowerA real play and plug security! It features POE (Power over Ethernet), with a single cable connecting each IP camera to the NVR for both power supply and video and single transmission. Easy wiring – the wiring process can’t be simpler for DIY enthusiasts and beginners
