Description
Main Features
Support access of multiple Camhipro smart front-end devices with human detection and face detection function.
Requires external POE expansion board power supply and network connection.
Support HDMI 4K, VGA 1080P HD Output.
Support ONVIF; Access third party;
Support web, hip2p, center platform management software camhipro, provide SDK development;
Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions;
Support multiple network services (support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL, IP searches, Alarm Center, etc.);
Support GB28181 protocol access to third-party platforms.
Product Specification
Model | SNO-N9108S | |
System | Operating System | Embedded Linux |
System resources | Simultaneous multi-channel real-time recording, playback, network operation, USB backup | |
Interface | Operator interface | 16-bit true color graphic menu operation interface, support mouse operation |
Preview | 1/2/4/6/9/10 | |
Video | Video input (IP) | 10*4K |
Video compression | H.265AI/H.265+(compatible H.265/H.264) | |
Display quality | Max:4K | |
Playback quality | 4K/5M/4M/3M/1080P | |
Decode | 4K（1）/5M（1+1）/4M(2+1)/3M（2+2）/1080P（4+1） | |
VR | Unsupport | |
human shape / Face | Support(depend on camera) | |
Audio | Audio compression | G.711A |
Intercom | support | |
Record& Playback | Recording mode | Manual>Alarm>Dynamic Detection>Timing |
Local payback | 4K（1）/5M（1+1）/4M(2+1)/3M（2+2）/1080P（4+1） | |
Search mode | Search by Time/Calendar/Event/Channel/Face | |
Record storage | HDD、Network | |
Backup mode | Network backup, USB hard disk, USB burner, SATA burner | |
External interface | Video output | 1ch VGA，1ch HDMI HD output |
Audio I/O | 1/1（3.5mm） | |
Alarm I/O | 0/0 | |
Network interface | 1*RJ45 10M/100M Adaptive Ethernet port | |
USB interface | 2*USB2.0 ports(one USB extension interface is reserved) | |
HDD | 1* SATA(Up to 14TB for each disk) | |
POE | Interface | 8 independent 100 Mbps PoE network interfaces |
Max Power | Max 30W for single port Max 54W in total (13.5W for each) | |
Supported | Standard IEEE 802.3at, IEEE 802.3af | |
General | ONVIF | Support |
Power supply | 52V DC | |
Power Consumption | <10W(Without HDD,only for NVR) | |
Work environment | Temperature:0℃－55℃ , Humidity:10%－90%RH , Atm:86kpa－106kp | |
Dimension | 255(L)*220(W)*42(H)mm | |
Weight | A total of about 1.6kg | |
With a high resolution of 8megapixels(3840×2160), capture videos in 3840P HD quality.
It is a huge advancement compared to 1080P Full HD or Super HD 5MP.
You never miss any important details. which enables you to see all objects very clearly.
H.265(HEVC) doubles the coding efficiency compared with its predecessor H.264.
Advanced H.265 compression technology lets you save on storage space which allows for longer recording times. H.265 technology compressing
your video without sacrificing any of the Ultra HD video quality.
This security system features Power Over Ethernet (PoE) technology, a single network cable run between this POE NVR and each PoE IP Camera provide both power, video and audio transmission, allowing you to position your cameras anywhere without a nearby power outlet.
POE NVR Easy installation and connection, Plug and play
With 8CH PoE Port
PoE NVR supports to connect to IOS, Android, Windows, and web browser. You can easily realize free connection with the camera in any of these four ways.
What is Included
NVR *1
Power Adapter*1
Mouse *1
User Manual *1
PC Menu Details :
Device Management
